Temperature/humidity monitor with Blynk

Build an Android or iOS app for your hardware with no coding!

EasyFull instructions provided38,845
Temperature/humidity monitor with Blynk

Things used in this project

Hardware components

Photon
Particle Photon
you can use a Photon or a Core (you do not need both)
×1
Spark Core
Particle Spark Core
you can use a Photon or a Core (you do not need both)
×1
DHT22 Temperature Sensor
DHT22 Temperature Sensor
you can alternatively use a DHT11, just make sure you modify the software in this line: #define DHTTYPE DHT22 // Sensor type DHT11/21/22/AM2301/AM2302
×1

Software apps and online services

Blynk
Blynk

Story

Read more

Schematics


Particle photon dht22 bb

Code

Particle firmware

C/C++
paste this code in Particle Build, then add the blynk and pietteTech_DHT libraries.
Flash and enjoy!
#include "blynk/blynk.h"
#include "PietteTech_DHT.h"

// system defines
#define DHTTYPE  DHT22              // Sensor type DHT11/21/22/AM2301/AM2302
#define DHTPIN   4         	    // Digital pin for communications
#define DHT_SAMPLE_INTERVAL   60000  // Sample every minute

//declaration
void dht_wrapper(); // must be declared before the lib initialization

// Lib instantiate
PietteTech_DHT DHT(DHTPIN, DHTTYPE, dht_wrapper);

// globals
unsigned int DHTnextSampleTime;	    // Next time we want to start sample
bool bDHTstarted;		    // flag to indicate we started acquisition
int n;                              // counter

//this is coming from http://www.instructables.com/id/Datalogging-with-Spark-Core-Google-Drive/?ALLSTEPS
char resultstr[64]; //String to store the sensor data

//DANGER - DO NOT SHARE!!!!
char auth[] = "01234567890123456789"; // Put your blynk token here
//DANGER - DO NOT SHARE!!!!

char VERSION[64] = "0.04";

#define READ_INTERVAL 60000

void setup()
{

  Blynk.begin(auth);

 DHTnextSampleTime = 0;  // Start the first sample immediately
 Particle.variable("result", resultstr, STRING);

 Particle.publish("DHT22 - firmware version", VERSION, 60, PRIVATE);

}


// This wrapper is in charge of calling
// must be defined like this for the lib work
void dht_wrapper() {
    DHT.isrCallback();
}

void loop()
{

  Blynk.run(); // all the Blynk magic happens here


  // Check if we need to start the next sample
  if (millis() > DHTnextSampleTime) {

	if (!bDHTstarted) {		// start the sample
	    DHT.acquire();
	    bDHTstarted = true;
	}

 if (!DHT.acquiring()) {		// has sample completed?

  float temp = (float)DHT.getCelsius();
  int temp1 = (temp - (int)temp) * 100;

  char tempInChar[32];
  sprintf(tempInChar,"%0d.%d", (int)temp, temp1);
  Particle.publish("The temperature from the dht22 is:", tempInChar, 60, PRIVATE);

  //virtual pin 1 will be the temperature
  Blynk.virtualWrite(V1, tempInChar);

  //google docs can get this variable
  sprintf(resultstr, "{\"t\":%s}", tempInChar);

  float humid = (float)DHT.getHumidity();
  int humid1 = (humid - (int)humid) * 100;

  sprintf(tempInChar,"%0d.%d", (int)humid, humid1);
  Particle.publish("The humidity from the dht22 is:", tempInChar, 60, PRIVATE);

  //virtual pin 2 will be the humidity
  Blynk.virtualWrite(V2, tempInChar);

  n++;  // increment counter
  bDHTstarted = false;  // reset the sample flag so we can take another
  DHTnextSampleTime = millis() + DHT_SAMPLE_INTERVAL;  // set the time for next sample
 }

}

}
