Gmail Photon Notifier

Have you ever been distracted by your phone while studying, but you still need it for schools email. We've got the solution for you!

IntermediateFull instructions provided4 hours62
Gmail Photon Notifier

Things used in this project

Hardware components

Photon
Particle Photon
×2
Solderless Breadboard Half Size
Solderless Breadboard Half Size
×2

Software apps and online services

Maker service
IFTTT Maker service
Particle Build Web IDE
Particle Build Web IDE
Google Sheets
Google Sheets

Story

Read more

Schematics

Schematic

Here is the Schematic For the notifier and control panel Photons that was used in this project.
Screen shot 2018 11 17 at 3 25 08 pm 40u5nxjtnm

Code

Control Panel code

C/C++
Here is the code used for the Control Panel photon that was used in this project. See operation section for more information in which it shows how it operates.
SYSTEM_THREAD(ENABLED)
bool buttonset = false;

void setup()
{
Particle.subscribe("email011", writetoscreen);
//receive from IFTTTT send to function
}


void writetoscreen(const char *event, const char *data)
{
    if(strcmp(event,"email011")==0)
    { //compare variable and determine meaning

        Particle.publish("email100","email011", 60);
}}

void loop() {
    if (System.buttonPushed() > 500) {
        Particle.publish("done100", "buttonpressed", 60);
        buttonset = true;
        delay(5000);
    }
}

Notifier Code

C/C++
Here is the code used for the notifier photon that was used in this project. See operation section for more information in which it shows how it operates.
int boardLed = D7;


void setup()
{
    Particle.subscribe("email100", flickerled);
    Serial.begin(230400);
    pinMode(boardLed,OUTPUT); // Our on-board LED output
    Particle.subscribe("done100",button);
}
void flickerled (const char *event, const char *data)
{

    if(strcmp(data, "1")==0)
{
        digitalWrite(boardLed,HIGH);
        Serial.println("1");
}
}
void button(const char *event, const char *data)
{
    if(strcmp(data,"buttonpressed")==0)
    {
        digitalWrite(boardLed,LOW);
        delay(15000);
}
}
